Processor

Application processor: 4-core 1.3 GHz ARM Cortex A53

Security processor: 108MHz ARM Cortex M3

Application processor: Quad-core ARM Cortex A53

Security processor: Single-core ARM Cortex M3

Application processor: Octa-core ARM Cortex A53

Security processor: Single-core ARM Cortex M3

Memory / Storage

1GB DDR RAM / 8GB Flash

1GB DDR RAM / 8GB Flash

2GB LPDDR3 + 16GB Flash

Display

N/A

7.0” touchscreen display - 800(w) x 1280(h) pixels

4.3” secure touchscreen display - 800(w) x 480(h) pixels

simulataneous 10 finger capacitive multitouch

 8.0" merchant touchscreen display -  5" secure touchscreen customer display

Operating system

Poynt OS

Poynt OS

Poynt OS & Android 10.1

Connectivity

WiFi 802.11 a/b/g/n

WiFi: 802.11 a/b/g/n dual channel 2.4, 5 GHz operation

Bluetooth 4.2

*Optional features: LTE/3G cellular modems

dual USB 2.0 ports (via optional dock)

Ethernet: 10/100 (via optional dock)

WiFi: 802.11 a/b/g/n/ac dual channel 2.4, 5 GHz operation

Bluetooth 4.2

Camera

Rear camera: 5 MP with flash and red targeting LED

Front camera: 5 MP with autofocus (7cm to infinity)

Back camera: 2MP

Camera: 5MP with autofocus (7cm to infinity)

Card reader

Hybrid MSR/Chip Reader

Magnetic stripe reader: Triple track (tracks 1, 2, 3),

high coercivity, bi-directional
Chip reader: ISO 7816, 1.8V, 3V, 5V;

synchronous and synchronous cards;

EMV Level 1 and 2 Type approved

Hybrid MSR/ Chip Reader

Magnetic stripe reader: Triple track (tracks 1, 2, 3),

high coercivity, bi-directional

Chip reader: ISO 7816, 1.8V, 3V, 5V;

synchronous and asynchronous cards;

EMV Level 1 and 2 Type approved

Magnetic stripe reader: Triple track (tracks 1, 2, 3),

high coercivity, bi-directional

Chip reader: ISO 7816, 1.8V, 3V, 5V;

synchronous and asynchronous cards;

EMV Level 1 and 2 Type approved

Audio/microphone

Mono speaker

Built-in microphone

Stereo speaker

Built-in microphone

Stereo speaker

Built-in microphone

Physical

76.3 mm x 154.0 mm x 25.4 mm | 201.6g

120.7 mm x 250.5 mm x 91.4 mm | 0.7 kg

 121mm x 275mm x 95mm | 0.7 kg

Protocols

Supports major NFC/contactless shemes,

ISO 14442 A&B, MiFare capable, ISO18092 capable

Supports major NFC/contactless schemes,

ISO 14443 A&B, MiFare capable, ISO18092 capable

Supports major NFC/contactless schemes,

ISO 14443 A&B, MiFare® capable, ISO18092 capable

Packed applications

Poynt Terminal, Poynt Register, Settlement, Help

Poynt Terminal, Poynt Register, Settlement, Help

Poynt Terminal, Poynt Register, Settlement, Help

Other features

3-axis accelerometer

Switchable full-scale ranges (≥ 5 ranges)

3-axis accelerometer, gyroscope, and compass

Switchable full-scale ranges (≥ 5 ranges)

Security

PCI PTS PED and SRED 4.x, End to end encryption

Supports TLS 1.2

PCI PTS PED and SRED 4.x, End to end encryption

Support TLS 1.2

PCI PTS PED and Secure Reading and Exchange of Data

(SRED) v4.x, End-to-end encryption Support TLS 1.2

Environmental

Operation 0º to 50ºC,

90% Maximum non-condensing up to 45ªC

Storage: -20ºC to 75ºC,

90% Maximum non-condensing up to 60ºC

Operation 0° to 40°C, 90% Maximum non-condensing

up to 45°C Storage: -20°C to 75°C, 90% Maximum

non-condensing up to 60°C

Operation 0° to 35°C, 90%

Storage: 5°C to 30°C

Certification

EMVCo L1 and L2 certification, PTCRB NFCC

EMVCo L1 and L2 certification, FCC, IC, and CE

EMVCo L1 and L2 certification, FCC, IC, and CE

EMV ready

Device is EMV ready for standarf PCI PTS 4.x

Smart Card: 500,000 reads. MSR: 500,000 swipes

Smart card reader life

Smart Card: 500,000 reads. MSR: 250,000 swipes

Smart Card: 500,000 reads. MSR: 500,000 swipes

Power

Battery: 2000mAh, 8.4 V, 800 cycles

Power Adaptor: Input 100 - 240 VAC, 50/60 Hz,

1.5 A | Output 12V / 3.33A

2000mAh, 8.4 V

Printer

Built in 2” thermal printer

Integrated thermal printer with graphics capabilites

≥ 80mm/s 18+ lines per second

Accomodates standard roll paper of 58mm (2.25 in.)

width x 25mm (1.0 in.) diameter, single ply - 3 rolls

included in box (6M / 20ft. each)

Built in 2” thermal printer

Integrated thermal printer with graphics capabilities ≥ 80mm/s

Accommodates standard roll paper of 58mm (2.25in.)

width x 40mm (1.6in.) diameter, single ply - 3 rolls

included in box (23M/75ft. each)

Voltage

AC input 100 - 240 VAC, 50/60 Hz; DC output 12V / 3.33A

AC input 100 - 240 VAC, 50/60 Hz;  DC output 5V/3.6A
